Details

01 Tool Holder
02 QuickFlex chuck
03 Collet
04 Collet nut
05 QuickFlex adapter
06 One-hand wrench (patent registered)
07 Thread for QuickFlex adapter and collet nut

02 QuickFlex chuck
07 Thread for QuickFlex adapter and collet nut
08 Short taper for radial centering and axial support of the QuickFlex adapter
09 Taper of the ER collet chuck
10 Polygonal torque transmission for QuickFlex adapter
11 Radial bending support of the QuickFlex adapter for high stiffness under load

Permanent accuracy of the run-out is guaranteed by two independent taper connections.

With ER collet

With QuickFlex mill arbor adapter

Quick and safe tool change with the one-hand wrench (patent registered).

Benefits

• ER collet chuck and quick change system in one Tool Holder.


• Minimal investment because you can start with the Tool Holder. You simply clamp the cutting tools directly in the Tool Holder using a standard ER collet chuck.
  The benefit for you: You start with what you need first and you buy later the quick change adapters when you like to add the quick change function.
• Maximal expandability  because you can complement with quick change adapters at any time.
  The benefit for you: You can start with a basic system at low costs and later you add the quick change adapters.
• The cutting tools can be pre-set while the machine is operating.
  The benefit for you: The time for tool change can be significatly reduced.
• Quick and safe tool change with the one-hand wrench (patent registered).

QuickFlex® adapters for REGO-FIX powRgrip®

QuickFlex - The quick change system for high performance and precision with QuickFlex adapters for REGO-FIX powRgrip®.



powRgrip^® collet chuck adapter



Mini floating chuck adapter MPHCC
DIN 6499, ISO 15488

The powRgrip® system:

• Highly precise powRgrip® collet
• QuickFlex powRgrip® collet chuck adapter
• powRgrip® clamping unit (PGU/PGC) (automatic or manual)



By accessing the YouTube video, you consent to your data being transmitted to YouTube: For details, see Privacy Policy under “Plugins and tools - YouTube”

By accessing the YouTube video, you consent to your data being transmitted to YouTube: For details, see Privacy Policy under “Plugins and tools - YouTube”

©REGO-FIX powRgrip®



• Simple
• The benefit for you: Tool is clamped in 8 seconds by pushing only one single button.
• Safe
  The benefit for you: No heat up – high clamping force.
• powRgrip®
  The benefit for you: The tool clamping system of today and the future

QuickFlex® adapters for BIG KAISER

QuickFlex^® adapters for BIG KAISER
for boring tools in sizes CBK1 up to CBK4

Tool combinations and work ranges:



Precision boring heads EWN, Series 112, Ø 0.4 – 24.8 mm

Precision boring heads EWN, Series 310, Ø 20 – 74 mm

Rough boring heads SW, Series 319, Ø 20 – 66 mm

Catalog Download

QuickFlex Adapter (PDF, 4 MB)

Product Portfolio (PDF, 4,2 MB)

Product Finder

Please refer to our Online Catalog for the precision Tool Holders that are suitable for your machine:



QuickFlex



To purchase, please contact your local distributor or you may purchase directly from
the Webshop:



Webshop

Additional products
