Comparison Test Part

87% faster operation with CoolSpeed® compared to a Machine Spindle



Application: Demo work piece
Machining: pocket milling, slot milling, drilling and engraving
Total machining time:
- CoolSpeed® mini: 2 minutes
- Machine Spindle: 15:45 minutes
Total time saving: 87%





Machine: Hermle C32
CoolSpeed® mini: CM-CE-F025-010-4-A
rpm: 60,000
Driven by: coolant
Coolant Pressure: 40 bar (580 psi)
Size of work piece: 38 mm x 38 mm x 10 mm
Material: SAE4140



VIDEO

Part for Electronics Assembly

Milling 86% faster with CoolSpeed® than with standard Driven Tool Holders Application: Part for electronics assembly



Maschining: milling
Total machining time:
- CoolSpeed® mini: 2 minutes
- Standard driven tool holders: 15 minutes
86% Faster!



Machine: Citizen Cincom L32
CoolSpeed® mini: CM-CE-R016-046-4-A
rpm: 55,000
Driven by: coolant
Coolant Pressure: 22 bar (319 psi)
Size of work piece: 26 mm x 5 mm
Material: 6061 T6 Aluminium

Pully Engraving

Engraving letters with CoolSpeed®



Application: Demo work piece for complete part machining
Machining: engraving
Machining time CoolSpeed® mini: 11 seconds



Machine: Okuma LB3000 EXII
CoolSpeed® mini: CM-CE-F016-046-4-A
rpm: 50,000
Driven by: coolant
Coolant Pressure: 16 bar (230 psi)
Outer diameter of work piece: 69 mm
Material: AISI 1018
Hardness: 126 HB (71 HRB)



11 Seconds!



VIDEO

Drilling holes dia. 0.0189“ on a turning center

Drilling holes dia. 0.0189“ on a turning center fast and efficient with high-speed Application: High-speed drilling of 12 holes diameter 0.0189“ and depth 0.300“ with a right angle CoolSpeed® mini spindle mounted in a boring bar holder
Machining: drilling
Machining time CoolSpeed® mini: 80 seconds



Machine: Doosan Lynx 2100LSY
CoolSpeed® mini: CM-CI-R016-016-4-A
rpm: 75,000
Driven by: cutting oil
Coolant Pressure: 60 bar (870 psi)
Size of work piece: Approx. 1” diameter x ¾”
Material: Copper
Hardness: 51 HRB



80 Seconds!
